उत्पादों का विवरण

Created with Pixso. घर Created with Pixso. उत्पादों Created with Pixso.
सौर प्रभारी नियंत्रक
Created with Pixso.

Wide Voltage 12V 24V 36V 48V 72V 96V MPPT Solar Charge Controller for LifePo4 Batteries Max PV Voltage 230V 30A 40A 50A 60A

Wide Voltage 12V 24V 36V 48V 72V 96V MPPT Solar Charge Controller for LifePo4 Batteries Max PV Voltage 230V 30A 40A 50A 60A

ब्रांड नाम: SZSSTH
मॉडल संख्या: एसएसटीएच-60ए
कीमत: CN¥1,024.15/pieces 1-49 pieces
विस्तृत जानकारी
उत्पत्ति के प्लेस:
ग्वांगडोंग, चीन
प्रकार:
एमपीपीटी
आवेदन:
चार्जर नियंत्रक, सौर प्रणाली
काम का समय (एच):
24 घंटे
अधिकतम पीवी शक्ति:
5400W
मैक्स पीवी वोल्टेज:
230V
प्रोडक्ट का नाम:
60 ए एमपीपीटी सौर चार्ज नियंत्रक
रेटेड वोल्टेज:
12वी 24वी 36वी 48वी 60वी 72वी 84वी 96वी ऑटो वर्क
MPPT दक्षता:
97%
अधिकतम वर्तमान:
60 ए
बैटरी प्रकार:
लेड एसिड/जेल/लाइफपो 4/ली-आयन/यूएसईआर
प्रभार विधा:
MPPT स्वचालित अधिकतम पावर ट्रैकिंग
प्रदर्शन:
एलसीडी स्क्रीन
आकार:
218*265*100 मिमी
वज़न:
2.6 किग्रा
प्रमाणपत्र:
सीटी
गारंटी:
1 वर्ष
पैकेजिंग विवरण:
पैकिंग: उपहार बॉक्स
पीसीएस/सीटीएन :4पीसी
कार्टन आयाम 50*34*27.2 सेमी
इकाई वजन: 2.6 किग्र
प्रमुखता देना:

30A MPPT solar charge controller

,

wide voltage solar controller for LifePo4

,

96V MPPT controller with 230V PV

उत्पाद का वर्णन

Wide voltage 12v 24v 36v 48v 72v 96v 30A 40A 50A 60A solar mppt controller for LifePo4 batteries MPPT solar charger controller

Product Description
Wide Voltage 12V 24V 36V 48V 72V 96V MPPT Solar Charge Controller for LifePo4 Batteries Max PV Voltage 230V 30A 40A 50A 60A 0

Product Features:

  • Innovative maximum power point tracking technology can significantly improve the energy utilization rate of the solar system, with a conversion efficiency of up to 97%;
  • Quickly scan the entire I-V curve, and efficiently track the maximum power point;
  • Three types of lead-acid batteries, sealed, colloidal, and open type, and lithium battery series are optional;
  • With automatic protection of overcharge, overdischarge, overload and short circuit;
  • RS485 communication interface, multi-machine communication communication is possible, which is convenient for viewing the operating parameters of the controller;
Detailed Images
Product packaging
Wide Voltage 12V 24V 36V 48V 72V 96V MPPT Solar Charge Controller for LifePo4 Batteries Max PV Voltage 230V 30A 40A 50A 60A 11
Product name 60A MPPT solar charge controller
Packing Box
PCS/CTN 4pcs
Carton Dimension 50X34X27.2CM
Unit Weight 2.6KG
Net weight (N.W) 10.5KG
Gross weight(G.W) 12.8KG
Product Paramenters
Wide Voltage 12V 24V 36V 48V 72V 96V MPPT Solar Charge Controller for LifePo4 Batteries Max PV Voltage 230V 30A 40A 50A 60A 12
